Micro Precision Z-Studio Z-ST 4c 4-Channel Amplifier
Micro Precision Z-ST 4c: a 4-channel, top-of-the-line amplifier with 160W/280W power at 4/2 Ohm, discrete circuitry, adjustable bias, and passive cooling. Features linear phase/amplitude and low-noise design for precise audio clarity.
Specifications
| Dimensions | 325 x 550 x 90mm. |
|---|---|
| Input capacitance | 5pF |
| Total idle current | 5 Ampere = 4 Kanäle a´ 1.25 Ampere. |
Measured Values
| Noise floor | A-Bewertet. -90dBV |
|---|---|
| Frequency response | 5 - 250.000 Hz @ -1dBV |
| Frequency response | 5 - 420.000 Hz @ -3dBV |
| Power output (4 ohm load) | 160 Watt @ 1% THD+N |
| Power output (2 ohm load) | 280 Watt @ 1% THD+N |
| Power output (4 ohm bridged) | 580 Watt @ 1% THD+N |
| Power output (2 ohm bridged) | Nicht zulässig. |
| Damping factor (10W) | 2700 |
| DC offset (typical) | 0,006 Volt. |
| Internal signal latency | 0.001 Millisekunde. |
| THD K2 (typical) | 0.002 % @ 5 Watt. |
| THD K3 (typical) | 0.005 % @ 5 Watt. |
Installed by Audio Edge
We sell every product as part of a system designed for your vehicle — consultation, installation, and tuning included. Tell us what you drive and we’ll tell you what this can do in your car.
